Silicone Heater For Valve Body Silicone Heater For Valve Body Silicone Heater For Valve Body Silicone Heater For Valve Body
Name:Silicone Heater For Valve Body
Voltage:5v,12,24v,48v,110v,120v,220v,380v or Customized
Wattage:Customized
Thickness:Conventional 1.5mm-3mm, can be thicker
Minimum size:10mmx 20mm
Maximum size:1200mm x 10000mm
Continuous use temperature:≤200℃
Temperature control:Digital display/Manual knob temperature control available
Wattage density:0.01-2w/cm², recommended power density: 0.1-0.8w/cm²
Wattage deviation:±3
3M adhesive::Yes or No
Shape:Any shape Customized
Mechanical compression:100KG/cm²
Wire tension:80N
  • image.png


    ● Silicone rubber heater has good flexibility, mainly composed of nickel-chromium alloy heating wire and silicone rubber high temperature insulation layer (Standard thickness is 1.5mm). ● Silicone rubber heater has the characteristics of fast heating, uniform temperature, high thermal efficiency, high strength, convenient use, safe life of up to 5 years, and not easy to aging. It can be in close contact with the heated object. ● The heating element of the silicon rubber heater can be wound or etched foil process. The winding element consists of a resistance wire wound on a glass fiber wire to provide support and stability. The etched foil heater is made of thin metal foil as a resistance element, the heating power can reach 1.2W/CM2, and the heating effect is more uniform. To ensure that the heat is transferred to any place needed. ● Silicone rubber heaters can be used in humid, non-explosive gas occasions, industrial equipment pipelines, tanks, etc. for mixing and heat preservation (oil drum heaters), and can be directly wound on the surface of the heated object. It can be used as medical equipment (such as blood analyzers, test tube heaters, medical care shapers, body shaping and slimming belts to compensate for heat, etc.).


    Voltage5v,12,24v,48v,110v,120v,220v,380v or Customized
    WattageCustomized
    ThicknessConventional 1.5mm-3mm, can be thicker
    Minimum size10mmx 20mm
    Maximum size1200mm x 10000mm
    Continuous use temperature ≤200℃
    Instantaneous max-tempe 280℃
    Temperature controlDigital display/Manual knob temperature control available
    Wattage density0.01-2w/cm², recommended power density: 0.1-0.8w/cm²
    Heating wire processEtching process, the temperature difference within 3-5℃.
    Wattage deviation±3%
    Insulation withstand voltage1500V/min
    Insulation resistance≥1000MΩ
    Mechanical compression100KG/cm²
    Wire tension80N
    ShapeAny shape Customized

                                  Any request, please do not hesitate to let me know.



    FotoJet (1).jpg







    1. Heat transfer machine                                     2. Oil drum heating

    3. Battery heating                                                4. 3D Printer heating bed

    5. Baking cup (pan) machine                               6. Heat-sealing machine heating sheet

    7. Heating of chemical pipelines                         8. Heating and heat preservation of medical equipment

    9. Large equipment heating                               10. Semiconductor processing equipment

    11. Food service equipment                               12. Lab analytical instruments

    13. Heating and heat preservation of various mechanical instruments

    14. Medical equipment, such as blood analyzers, respiratory therapy devices and hydrotherapy

    15. Antifreeze for Aerospace, Aircraft instruments and Hydraulic equipment

        ......

    (Part for your information, in fact, silicone rubber heaters can be used in many industries that require heating, heat preservation, dehumidification and antifreeze)


    How to order :

    1. What substance do you need to heat? (Such as water, oil, resin, iron, copper, air, plastic, nitrogen, etc.)

    2. How much of this substance do you need to heat?

    3. What is the power supply voltage?

    4. What is the initial temperature?

    5. What is the final target temperature?

    6. After the heater starts, how quickly do you want to reach the final temperature?

    7. Please describe the application of the product in detail.
